80W Solar Panel (PERC MONO)
https://www.dualcom.co.nz/shop/80w-perc-mono-solar-panel-17 https://www.dualcom.co.nz/web/image/product.template/17/image_1920?unique=58aabcaDUALCOM
Dualcom Technology is an Importer/Distributor of Lighting and Solar Energy products. Established 2009 the team is focused on product solutions for Commercial, RV and Marine industries.
SOL-80W-PERC12-MONO
Specifications
Maximum Power (Pmax) | 80W |
Voltage (Vmp) | 18.5V |
Current (Imp) | 4.32A |
Voltage (Voc) | 23.3V |
Current (Isc) | 4.4A |
Module Efficiency | 19.75% |
Cell Type | MONO PERC |
Cable | 4mm (Cross Sectional) |
Module Dimensions (mm) | 350 x 1170 x 35 |
Weight (Kg) | 5.0 |
DATASHEET (80W PERC) | Download |
---|
Passivated Emitter and Rear Contact (PERC) solar cells are modified conventional cells that enable the cells to produce 6 to 12 percent more energy than conventional solar panels. PERC cells have an extra layer within the back side of the cell. This allows some of the sun’s rays to reflect back into the solar cell, giving them another opportunity to be turned into energy.
Shingled modules have no visible busbars and solar cells are cut into five or six strips and connected with an electrically conductive adhesive. The three key advantages of the shingled solar panel design are to produce more power, improve reliability and are aesthetically pleasing.
Features
- MONO PERC Solar cells
- Reinforced frame with aluminum angle
- 35mm Frame with a support surface of 1.2mm thickness
- 4mm2 Twin Red / Black Cable to MC4 from Diode Box
