ELV (GEN4) IP65 Batten Light - 600MM

The ELV GEN4 600mm LED Batten Light is a high-output, energy-efficient lighting solution designed for 12V and 24V DC electrical systems. Built for demanding environments, this commercial-grade LED batten delivers powerful, reliable illumination with IP65 ingress protection and IK08 impact resistance, making it ideal for industrial, utility, marine and off-grid applications.

Operating across a wide 10–32V DC input range, the GEN4 batten can be powered directly from compatible battery systems or suitable extra-low-voltage power supplies. This makes it particularly well suited to solar-powered facilities, remote infrastructure and installations where conventional 230V AC lighting is impractical.

Producing an impressive 2,000 lumens from just 20W, the integrated LED provides bright, efficient 5000K daylight illumination. Its wide 150° beam angle delivers excellent light distribution, making it ideal for larger utility rooms, workshops, equipment shelters, engine rooms and general-purpose lighting applications.

The robust construction features an IP65 rating, providing protection against dust and water jets, while the IK08 impact rating offers additional resistance to accidental damage. Optional zero-gap surface mounting brackets allow for a neat, professional installation.

$ 145.00 $ 145.00
RRP: incl. GST

Add to cart
Buy now
You have already submitted a query for this product today. Add to wishlist


Contact Us
DATASHEET (ELV GEN4) Download
IK Rating or “Impact Protection” (the K is from 'Kinetic' to differentiate from IP rating) is defined in international standards and indicates the level of resistance an electrical enclosure provides against mechanical impact.
Extra low voltage (ELV) means voltage of 50V or less (AC RMS), or 120V or less (ripple-free DC).
Protected against 5 joules impact - Equivalent to impact of 1.7kg mass dropped from 300mm above impacted surface.
No, However it is important when installing with a step down transformer to make sure the transformer is SELV compliant (Separated or Safety Extra Low Voltage).
Separated or Safety Extra Low Voltage (SELV) system is an extra low voltage electrical circuit that is electrically separated from other circuits that carry higher voltages, isolated from earth and from the protective earth conductors of other circuits.
  • 20W integrated LED batten light
  • 2,000 lumens of light output
  • 10–32V DC wide input voltage
  • Compatible with 12V and 24V DC systems
  • 5000K Daylight White colour temperature
  • Wide 150° beam angle for excellent light distribution
  • IP65 rated – dust-tight and protected against water jets
  • IK08 impact resistance – withstands impacts up to 5 joules
  • Extra-low-voltage (ELV) operation
  • Suitable for battery-powered and off-grid lighting systems
  • Integrated LED PCB for efficient, reliable operation
