BMPRO - ASPERO

Name: BMPRO - ASPERO
Price: 865.22 NZD
Availability: InStock

*ASPower can be retrofitted in place of a J35 system (Display sold separately)

The BMPRO ASPower is an advanced all-in-one battery management system designed for modern caravans and RVs. Compatible with LiFePO₄ lithium and lead-acid batteries, ASPower intelligently manages power from 240V AC mains, solar panels, and your tow vehicle, simultaneously powering your 12V appliances while charging your house battery.

Featuring intelligent multi-stage charging algorithms and an automatic battery preservation mode, ASPower helps maximise battery performance and extend battery life. With 14 protected DC outputs, 30A battery charging, and support for up to 450W of solar input, it provides a complete power management solution for on-road and off-grid adventures.

ASPower can be expanded with a range of BMPRO accessories, including the PX500 External Shunt for high-current battery monitoring, ControlNode103 for smartphone connectivity, the JHub Monitoring Pack, and the JControl Battery Monitor for advanced monitoring and control.

See FAQ for J35 retrofit compatibility

Features:

All-in-one RV power management system
Compatible with LiFePO₄ and Lead Acid batteries*
Multi-input charging from AC mains, solar, and vehicle
30A multi-stage battery charger
35A maximum DC output
Integrated 27A MPPT solar regulator (up to 450W)
14 protected 12V DC outputs
Supports battery banks up to 600Ah
Automatic battery preservation mode
Expandable with JHub, JControl, ControlNode103 & PX500
Direct retrofit replacement for BMPRO J35 systems

* Supplied pre-configured for LiFePO₄ batteries. Battery chemistry can be changed using a compatible BMPRO controller, including ASDisplay, JHub Tablet, JHub App, or JControl.

The BMPRO ASPower delivers intelligent charging, efficient power distribution, and seamless system expansion, making it the ideal battery management solution for today's lithium-powered caravans and RVs.

$ 995.00

Add to cart

Buy now

Add to wishlist

Charge Current (Solar)	27A
Charge Type	MPPT
Max Solar Input (Watts)	450W
Input Voltage (DC AUX)	10 - 16V
Input Voltage (AC)	230-240vAC
Charge Current (AC)	30A
Input Voltage (Solar)	15 - 25V (max)
Battery Voltage	12V
Battery Chemistry	Flooded / AGM / WET \| Lithium (LiFeP04)
Battery Selection Mode	Manual
Smart Connect Ready	Yes
Dimensions (mm)	307 x 206 x 68 (BMS) \| 150 x 90 x 15 (Display)
Cooling	Thermally Controlled Fan
Weight (Kg)	2

MANUAL (ASPERO)	Download

I think one of my loads is not receiving power?

The load may be faulty, activating the protective electronic fuse and turning the load off. If this is the case, the LED Status Indicator on the ASPower will flash a solid red. Should you encounter any faulty loads, please contact your caravan dealership.

I am upgrading my J35 with the ASPERO, is it compatible?

Yes. The ASPERO is compatible with the following version displays and nodes:

JCONTROL Rev 4+
JHUB with ControlNode 102
JHUB with ControlNode 103

I have a JHUB tablet display, is this compatible?

Yes. The ASPERO is compatible with the JHUB paired with ControlNode102 or ControlNode103

None of my loads appear to be powered, but I can still use the ASDisplay?

All loads will power down, but the ASDisplay will still be in use if the ASPower was put into ECO Mode. The ASPower will be put into ECO Mode if: The ECO Mode button on the ASDisplay has been pressed. This turns off power to all caravan loads connected to the ASPower, except output 14. Check if there is a green LED light next to the ECO Mode button on the ASDisplay. If there is, press the ECO Mode button again to exit ECO Mode. Battery voltage is very low. The ASPower will enter ECO Mode to conserve remaining battery voltage, which will disable power to all caravan loads connected to the ASPower. Connect the ASPower to a power source and begin battery charging.

I’ve fitted a battery to the ASPower, but it’s not detected by the ASDisplay?

Check the following: The battery connections are tight and not loose or corroded. Battery polarity: red lead is positive, black lead is negative. The battery fuse on the ASDisplay is fitted and not blown. The correct value is 40A.
