ELV (GEN4) IP65 Batten Light - 300MM

The ELV GEN4 300mm LED Batten Light is a compact, durable and energy-efficient lighting solution designed for 12V and 24V DC electrical systems. Built for demanding environments, this commercial-grade LED batten combines excellent light output with IP65 ingress protection and IK08 impact resistance, making it ideal for industrial, utility, marine and off-grid applications.

Operating across a wide 10–32V DC input range, the GEN4 batten can be powered directly from compatible battery systems or suitable extra-low-voltage power supplies. This makes it particularly well suited to installations where conventional 230V AC lighting is impractical or where an extra-low-voltage lighting system is preferred.

Producing 1,000 lumens from just 10W, the integrated LED delivers bright, efficient 5000K daylight illumination. Its wide 150° beam angle provides excellent light distribution, making it ideal for utility rooms, equipment enclosures, engine rooms, service areas and general-purpose lighting.

The robust enclosure is designed for long-term reliability, with an IP65 rating providing protection against dust and water jets, while the IK08 rating offers additional resistance to accidental impact. Optional zero-gap surface mounting brackets allow for a neat, professional installation.


Typical Applications

  • Public utility facilities – toilet blocks, service rooms and amenities
  • Off-grid and solar-powered buildings – lighting powered from 12V or 24V battery systems
  • Marine and engine rooms – durable lighting for demanding environments
  • CCTV and communications infrastructure – equipment shelters and service enclosures
  • Industrial and commercial installations – workshops, plant rooms and maintenance areas
  • Remote infrastructure – installations where extra-low-voltage lighting is preferred
$ 105.00 $ 105.00
RRP: incl. GST

Add to cart
Buy now
You have already submitted a query for this product today. Add to wishlist


Contact Us
DATASHEET (ELV GEN4) Download
IK Rating or “Impact Protection” (the K is from 'Kinetic' to differentiate from IP rating) is defined in international standards and indicates the level of resistance an electrical enclosure provides against mechanical impact.
Extra low voltage (ELV) means voltage of 50V or less (AC RMS), or 120V or less (ripple-free DC).
Protected against 5 joules impact - Equivalent to impact of 1.7kg mass dropped from 300mm above impacted surface.
No, However it is important when installing with a step down transformer to make sure the transformer is SELV compliant (Separated or Safety Extra Low Voltage).
Separated or Safety Extra Low Voltage (SELV) system is an extra low voltage electrical circuit that is electrically separated from other circuits that carry higher voltages, isolated from earth and from the protective earth conductors of other circuits.
  • 10W integrated LED batten light
  • 1,000 lumens of light output
  • 10–32V DC wide input voltage
  • Compatible with 12V and 24V DC systems
  • 5000K Daylight White colour temperature
  • Wide 150° beam angle for excellent light distribution
  • IP65 rated – dust-tight and protected against water jets
  • IK08 impact resistance – withstands impacts up to 5 joules
  • Extra-low-voltage (ELV) operation
  • Suitable for battery-powered and off-grid lighting systems
  • Integrated LED PCB for efficient, reliable operation
  • Optional zero-gap surface mounting brackets
