Solar Camera Power System – 75Ah Lithium | IP66 Steel Enclosure

Name: Solar Camera Power System – 75Ah Lithium | IP66 Steel Enclosure
Availability: OutOfStock

The Dualcom Solar Camera Power System is a professionally engineered off-grid power solution designed to provide reliable, autonomous power for CCTV cameras, communications equipment and other remote monitoring applications.

Built into a robust IP66 powder-coated steel enclosure, each system is fully assembled, tested and configured in-house by Dualcom before dispatch. Designed for demanding outdoor environments, the system integrates premium Victron Energy components with intelligent battery monitoring and remote connectivity, providing exceptional reliability and visibility of your power system.

Using the integrated 4G communications gateway, users can securely access the system through the Victron Remote Management (VRM) Portal to monitor battery state of charge, solar performance, charging history, system voltages and operational status from anywhere with an internet connection.

Ideal for remote CCTV, ANPR cameras, security systems, telemetry, environmental monitoring, communications equipment and other off-grid applications.

Applications

CCTV Camera Systems
ANPR Cameras
Security & Surveillance
Remote Communications
Telemetry Systems
Environmental Monitoring
Access Control
Temporary Site Monitoring
Infrastructure Monitoring

Dualcom can customise each power system to suit your project requirements, including alternative battery capacities, solar panel sizes, communications options, enclosure sizes and customer-specific power configurations.

Add to wishlist

Input Voltage (Solar)	100V (max)
Max Solar Input (Watts)	220W (12V)
Charge Current (Solar)	15A
Charge Type	MPPT
Battery Chemistry	Lithium (LiFeP04)
Battery Capacity	75Ah
Battery Voltage	12V
Smart Connect Ready	VE-Direct \| Bluetooth
Low Voltage Disconnect	10.5V
IP Grade	IP66
Cooling	Self Cooling / Heatsink
Weight (Kg)	22
Dimensions (mm)	500H × 300W × 200D

Heavy-duty IP66 powder-coated steel enclosure
Professionally engineered and assembled in New Zealand
Premium Victron Energy charging and monitoring components
Intelligent lithium battery management
Real-time remote monitoring via the Victron VRM Portal
4G connectivity for remote diagnostics and performance monitoring
Fused 12V DC power distribution
Suitable for CCTV, communications, telemetry and remote infrastructure applications
Integrated Components
IP66 Steel Enclosure (500H × 300W × 200D)
Victron SmartSolar MPPT 75/15 Solar Charge Controller
Victron SmartShunt Battery Monitor
75Ah 12V LiFePO₄ Lithium Battery
4-Way Fused 12V DC Distribution Block
4-Pole Negative Busbar
